Mi-Light DP3S DALI DT8 3 IN 1 Dimming Panel (DALI)
Transform your space with a wide range of lighting possibilities.
Article No. |
181374 |
EAN |
6970602181374 |
Terms and Conditions
14-day money-back guarantee
Delivery: Pick up at our warehouse in Helsingborg or tracked shipping 1-3 business days.
Description
The MiBoxer DP3S is a versatile wall-mounted touch panel designed to control a wide range of DALI-compatible lighting systems. This advanced panel offers control over RGB, RGBW, and RGB+CCT light sources, providing exceptional flexibility and customization options. Residential: Create dynamic lighting scenes in living rooms, bedrooms, and kitchens.
Commercial: Enhance ambiance in hotels, restaurants, and offices.
Hospitality: Tailor lighting to different moods and occasions.
Specification
| Application | For multi-colour RGB, RGBW and RGBCCT installationsType of installation: Flush-mounted (standard fi60 box)Rated voltage: DALI Bus stationNumber of zones/channels supported: 1 to 4Color: WhiteControlling method: Wired - DALICooperation with external systems:DALI Bus Standard interface IEC62386-102, 207, 209Model number: DP2SCommunication type: One-wayGlass panel: YesWorking temperature: -20 – 60°CTouch buttons: YesIP class: IP20Dimensions[mm]: L86 x W86 x H33Certification: RoHS, CE, UKCAWarranty: 2 years |
