Mi-Light X1 DMX512 Master Single Color (DMX512)
Article No. |
181190 |
EAN |
6970602181190 |
Terms and Conditions
14-day money-back guarantee
Delivery: Pick up at our warehouse in Helsingborg or tracked shipping 1-3 business days.
Description
Mi-Light / MiBoxer X1 DMX512 Master (Single Color)
The Mi-Light / MiBoxer X1 DMX512 Master is an elegant and feature-rich wall-mounted control panel designed to control single color DMX512-compatible lighting systems. This touch panel offers precise and intuitive brightness dimming, making it ideal for professional lighting installations in homes, offices, retail spaces, hotels, and restaurants. With its wireless 2.4GHz RF functionality, it can also act as a DMX512 transmitter, providing flexibility in system design.
Key Features:
- DMX512 Output: Directly controls DMX512-compatible single color lighting fixtures and drivers.
- Single Color Control: Dedicated for precise brightness regulation of single color LED products.
- High-Precision Touch Panel: Provides smooth and intuitive dimming control via a sensitive touch surface.
- 2.4GHz RF Transmitting Function: Capable of wirelessly transmitting DMX512 signals via 2.4GHz, reducing the need for long DMX cables.
- Standard 86-type Wall Box Installation: Easy to install into a standard wall box, offering a clean and integrated appearance.
- Auto-transmitting & Auto-synchronizing:
- Auto-transmitting: Signals can be forwarded to other 2.4GHz RF receivers within 30 meters.
- Auto-synchronizing: Multiple X1 panels can synchronize their dimming modes when within range of each other and controlled in the same manner.
- Memory Function: The panel's settings (last selected brightness) are automatically saved even after power interruption.
- Long Range (RF): Up to 30 meters in open area for wireless control.
Applications:
The X1 is ideal for controlling single color LED strips, spotlights, or other DMX512-compatible lighting devices in professional environments requiring precise and centralized brightness control. Its dual functionality as a DMX512 master and 2.4GHz RF transmitter offers great flexibility in installation.
Documents
Specification
| Product Name | DMX512 Master (Single Color) |
| Model No. | X1 |
| Input Voltage | 100-240V~ 50/60Hz |
| RF | 2.4GHz |
| RF Transmitting Power | 6dBm |
| RF Control Distance | 30m |
| IP Rate | – (No specified IP rating, likely for indoor use) |
| Working Temperature | -20~60°C |
